@Ada

The result shows there is not enough ASIC! Repair it.

What's the meaning of the L3+ singleboard test result
@Ada

The temp sensor model in test file configuration does not match the one in hashboard. Correct it.

L3+ single-board test-- temperature error
@Ada

The temp sensor model in test file configuration does not match the one in hashboard. Correct it.

L3+ single-board test-- temperature error
@Ada

Check the facility environment temprature, can not too low or too high. Try to keep the temprature above 0°C.

T17e always disconnections with the hashbaords
@Ada
Compare the voltage domains of CLK before and after to see if they are the same. Also, check the specific error reported by the hashboards. It's possible that 1.1V is within the normal range.
All peripheral CLK signals of S9 are high, around 1.1V. What could be the issue?
@Ada
The USB-TTL did not connected well to the tester. Check the wire connected to Ground.
What could be the problem causing frequent garbled output on the fixture?
@Ada
No. they can not be mixes. Different version with different specification.
Can 1397AD and 1397AG be mixed and used interchangeably?
@Ada
The pic program is failed. Re-program the PIC with the Pickit.
Update the official website firmware results in the hashrate as shown in this image. What is the problem?
@Ada
Replace the IO port and then test again.
The hashboard can pass the single-board test but chip 34 RI voltage only 1.3V.
@Ada
Check the temprature sensor IC U88, replace it. Then there are domain voltage 8.5V and all chips hashrate [114],Nounce[912].
All the chips have been tested, but temperature 0 and all chips' hashrate reported as [00].
@Ada
Check the temprature sensor IC U88, replace it. Then there are domain voltage 8.5V and all chips hashrate [114],Nounce[912].
All the chips have been tested, but temperature 0 and all chips' hashrate reported as [00].
@Ada
It is possible that either chip 56 or chip 57 is faulty, or there could be an issue with the 0.8V voltage supply.
S9 single-board test showed Nonce [0] from chip 56, why this happened?
